3km WiFi HaLow Bridge
3km WiFi HaLow Bridge
The 3km WiFi HaLow Bridge is a long-range wireless connectivity solution based on the IEEE 802.11ah (WiFi HaLow) standard. It enables stable data transmission over distances up to 3 kilometers, filling the gap between short-range WiFi and high-cost long-distance communication technologies.
Total Price：{{ totalPrice }}
- Describe
| Item | Parameter Details |
|---|---|
| Communication Standard | IEEE 802.11ah（WiFi HaLow） |
| Frequency Band | 902-928MHz (USA)863-868MHz (EUR) |
| Channel Bandwidth | 8MHz |
| Data Rate | 16Mbps |
| Receiver Sensitivity | 1M PPDU = 10-105dBm8M PPDU MCS=0 = 95dBm8M PPDU MCS=7 = 81dBm |
| Max Network Nodes | Up to 31 access points |
| Transmit Power | Max 33dBm ±2dBm |
| Modulation | BPSK, QPSK, QAM16, QAM64 |
| Transmission Range | 3km (LOS), 500m (NLOS) |
| Security Protocol | WPA2-PSK |
| Encryption | AES |
| Ethernet Port | 10/100Mbps |
| Power Supply | DC12V/1A |
| LED Indicators | Power, AP/Client Mode, Signal Strength |
| Input Voltage | DC12V1A |
| Operating Temperature | -20℃ ~ 70℃ |
| Storage Temperature | -30℃～80℃ |
| Operating Humidity | 10%～90% |
| Storage Humidity | 5%～95% |
| Dimensions | 1148430mm (Excluding Antenna） |
| Weight | 105g |
