300m Wall-Penetrating Wireless Bridge
300m Wall-Penetrating Wireless Bridge
A 300m wall-penetrating wireless bridge is designed for long-range, high-stability wireless connectivity, capable of transmitting data through obstacles like walls or buildings while maintaining robust performance.
Total Price：{{ totalPrice }}
- Describe
| Item | Parameter Details |
|---|---|
| Communication Standard | IEEE 802.11ah（WiFi HaLow） |
| Frequency Band | 902-928MHz (USA)863-868MHz (EUR) |
| Channel Bandwidth | 8MHz |
| Data Rate | 16Mbps |
| Receiver Sensitivity | 1M PPDU = 10-105dBm8M PPDU MCS=0 = 95dBm8M PPDU MCS=7 = 81dBm |
| Max Network Nodes | Up to 8 access points |
| Transmit Power | Max 20dBm (100mW) |
| Modulation | BPSK, QPSK, QAM16, QAM64 |
| Transmission Range | 500m (LOS), 300m (NLOS) |
| Security Protocol | WPA2-PSK |
| Encryption | AES |
| Ethernet Port | 10/100Mbps |
| Serial Port | TTL Level |
| Baud Rate | 115200 |
| Power Supply | DC5V/1A, DC12V/1A |
| LED Indicators | Power, AP/Client Mode, Signal Strength |
| Input Voltage | 5V1A |
| Operating Temperature | -20℃ ~ 70℃ |
| Storage Temperature | -30℃～80℃ |
| Operating Humidity | 10%～90% |
| Storage Humidity | 5%～95% |
| Dimensions | 746924mm (Excluding Antenna） |
| Weight | 49.6g |
